Features:
- Rolled threads maintain material grain structure improving thread strength up to 20%
- Each MegaFORCE Retention knob is magnetic particle tested to ensure material integrity and physical soundness
- Tested at 2.5X the pulling forces of the drawbar
Product Specifications
Taper Size | CAT40 |
Degree | 15 Degree |
Head Diameter (Inch) | 0.747" |
Neck Diameter (Inch) | 0.548" |
Body Diameter (Inch) | 0.641" |
Flange to Top Length (Inch) | 1.024" |
Flange to Center of head Length (Inch) | 0.787" |
Thread | 5/8-11 |
