Product Specifications
| Manufacturer Part Number | 75077180 |
| Functional Length (mm) | 125.00mm |
| Head Length (mm) | 26.00mm |
| Shank Width (mm) | 20.00mm |
| Height of Tool Holder Shank (mm) | 20.00mm |
| Functional Width (mm) | 10.30mm |
| Cutting Direction | Neutral |
| Insert Clamping System | S |
| Tool Cutting Edge Angle (Degree) | 72.5 Degree |
| Tool Cutting Edge Angle Code | V |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 162.5 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 72.5 Degree |
| Insert Shape Code | V |
| Shank Type | Square shank |
| Product Type | Indexable Turning Toolholder |
