Product Specifications
| Manufacturer Part Number | 75034361 |
| Cutting Diameter (mm) | 40.00mm |
| Connection Diameter Machine Side (mm) | 32.00mm |
| Shank Diameter (mm) | 32.00mm |
| Maximum Helical Interpolation Hole Diameter (mm) | 79.60mm |
| Minimum Helical Interpolation Hole Diameter (mm) | 77.06mm |
| Protruding Length (mm) | 140.00mm |
| Shank Length (mm) | 155.00mm |
| Overall Length (mm) | 200.00mm |
| Maximum Depth of Cut (mm) | 15.00mm |
| Cutting Pitch Differential | 1 |
| Cutting Pitch Density | Normal |
| Rake Radial Angle (Degree) | -12.4 Degree |
| Rake Radial Angle (Degree) | -12.4 Degree |
| Rake Orthogonal Angle (Degree) | -12.4 Degree |
| Axial Rake Angle (Degree) | 6 Degree |
| Tool Cutting Edge Angle (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 90 Degree |
| Maximum Ramping Angle (Degree) | 1.5 Degree |
| Maximum Rotational Speed (rpm) | 14600 rpm |
| Shank Type | Cylindrical |
| Product Type | Indexable Square-Shoulder End Mill |
