Product Specifications
| Manufacturer Part Number | 74077372 |
| Inscribed Circle Diameter (Decimal Inch) | 0.313" |
| Inscribed Circle Diameter (mm) | 7.94mm |
| Theoretical Cutting Edge Length (Decimal Inch) | 0.313" |
| Theoretical Cutting Edge Length (mm) | 7.94mm |
| Insert Thickness (Decimal Inch) | 0.125" |
| Insert Thickness (mm) | 3.18mm |
| Insert Width (Decimal Inch) | 0.313" |
| Insert Width (mm) | 7.94mm |
| Clearance Angle Major (Degree) | 11 Degree |
| Cutting Edge Count | 4 |
| Cutting Geometry Type Technical | C1 |
| Insert Included Angle (Degree) | 90 Degree |
| Material | Carbide |
| Product Type | Indexable Drill Insert |
