Product Specifications
| Manufacturer Part Number | 10271561 |
| Depth of Cut Maximum in Feed Direction Side (Decimal Inch) | 0.450" |
| Center Cutting Capability | Yes |
| Cutting Geometry Type | XSE450 |
| Coating | AXT |
| Coolant Supply Property | No |
| Cutting Diameter (Decimal Inch) | 0.375" |
| Contact Surface Diameter Machine Side (Decimal Inch) | 0.364" |
| Face Cutting Edge Count | 3 |
| Flute Helix Angle (Degree) | 45 Degree |
| Functional Length (Decimal Inch) | 0.720" |
| Overall Length (Decimal Inch) | 1.158" |
| Cutting Edge Count | 3 |
| Corner Radius (Decimal Inch) | 0.010" |
| Torque (Nm) | 12.00nm |
| Product Series | XSE450 |
| Product Type | Corner Radius Milling Tip Insert |
