Product Specifications
| Manufacturer Part Number | 10260238 |
| Depth of Cut Maximum 1 (mm) | 4.00mm |
| Depth of Cut Maximum 2 (mm) | 1.50mm |
| Depth of Cut Maximum 3 (mm) | 7.50mm |
| Cutting Pitch Density | Normal |
| Coolant Supply Property | 1 |
| Cutting Diameter 1 (mm) | 250.00mm |
| Cutting Diameter 2 (mm) | 246.00mm |
| Cutting Diameter Maximum 2 (mm) | 260.70mm |
| Cutting Diameter Maximum 3 (mm) | 260.35mm |
| Cutting Direction | Right Hand |
| Tool Cutting Edge Angle 1 (Degree) | 40.00 Degree |
| Tool Cutting Edge Angle 2 (Degree) | 20.00 Degree |
| Functional Length 1 (mm) | 63.00mm |
| Functional Length 2 (mm) | 63.15mm |
| Rotational Speed Maximum | 5000 rpm |
| Shank Type | Arbor |
| Uncut Thickness (mm) | 0.32mm |
| Peripheral Effective Cutting Edge Count | 14 |
| Product Series | R220.43 |
| Product Type | Indexable Chamfer & Angle Face Mill |
