Seco Tools

Seco Tools 10255167 | R220.42-0050-040-LNXO.4A 50.00mm Cutting Diameter x 40.00mm Depth of Cut Maximum x 65.00mm Functional Length x 11.00 Degree Rake Axial Angle 4 Cutting Edge 13600 rpm Rotational Speed R220.42 Indexable Square-Shoulder Face Mill

Seco Tools 10255167 | R220.42-0050-040-LNXO.4A 50.00mm Cutting Diameter x 40.00mm Depth of Cut Maximum x 65.00mm Functional Length x 11.00 Degree Rake Axial Angle 4 Cutting Edge 13600 rpm Rotational Speed R220.42 Indexable Square-Shoulder Face Mill

SKU: 23346601

$2,010.00 USD
$2,010.00 USD $2,010.00 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

UPC:

Weight: 558 Grams

Ver todos los detalles

Product Specifications
Manufacturer Part Number 10255167
Depth of Cut Maximum in Feed Direction Side (mm) 40.00mm
Cutting Pitch Density Normal
Coolant Supply Property 1
Cutting Diameter (mm) 50.00mm
Contact Surface Diameter Machine Side (mm) 47.09mm
Tool Cutting Edge Angle in Feed Direction Side (Degree) 90.00 Degree
Functional Length (mm) 65.00mm
Number of Flutes 4
Rotational Speed Maximum 13600 rpm
Shank Type Arbor
Peripheral Effective Cutting Edge Count 4
Product Series R220.42
Product Type Indexable Square-Shoulder Face Mill
