Product Specifications
| Manufacturer Part Number | 10198680 |
| Fixing Hole Diameter (mm) | 3.00mm |
| Inscribed Circle Diameter (mm) | 7.06mm |
| Curved Cutting Edge Radius (mm) | 10.00mm |
| Corner Radius (mm) | 0.80mm |
| Insert Thickness (mm) | 2.78mm |
| Cutting Edge Count | 3 |
| Clearance Angle Major (Degree) | 12 Degree |
| Insert Rake Angle (Degree) | 7 Degree |
| Insert Hand | Neutral |
| Cutting Geometry Type | M |
| Cutting Geometry Type Technical | M06 |
| Pocket Seat Code of The Cutter | 218.19-100 |
| Insert Size And Shape | 218.19-100 |
| Insert Shape Code | 218.19 |
| Material | Carbide |
| Product Type | Milling Insert |
