Product Specifications
| Manufacturer Part Number | 10092429 |
| Depth of Cut Maximum in Feed Direction Side (Decimal Inch) | 0.500" |
| Cutting Pitch Density | Normal |
| Coolant Supply Property | No |
| Cutting Diameter (Decimal Inch) | 3.000" |
| Connection Bore Diameter (Decimal Inch) | 1.000" |
| Connection Bore Diameter (Decimal Inch) | 1.000" |
| Connection Diameter Machine Side (Decimal Inch) | 1.000" |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.551" |
| Cutting Direction | Neutral |
| Tool Cutting Edge Angle in Feed Direction Side (Degree) | 90.00 Degree |
| Rotational Speed Maximum | 10000 rpm |
| Shank Type | Arbor hole |
| Peripheral Effective Cutting Edge Count | 4 |
| Product Series | 335.18 |
| Product Type | Indexable Slotting Cutter |
