Product Specifications
| Manufacturer Part Number | 10092368 |
| Depth of Cut Maximum in Feed Direction Side (Decimal Inch) | 0.312" |
| Body Diameter (Decimal Inch) | 0.547" |
| Cutting Pitch Density | Normal |
| Coolant Supply Property | No |
| Cutting Diameter (Decimal Inch) | 1.250" |
| Connection Diameter Machine Side (Decimal Inch) | 0.625" |
| Cutting Direction | Right Hand |
| Tool Cutting Edge Angle in Feed Direction Side (Degree) | 90.00 Degree |
| Protruding Length (Decimal Inch) | 3.610" |
| Shank Length (Decimal Inch) | 4.370" |
| Overall Length (Decimal Inch) | 5.500" |
| Rotational Speed Maximum | 18700 rpm |
| Shank Type | Cylindrical |
| Peripheral Effective Cutting Edge Count | 1 |
| Product Series | R335.18 |
| Product Type | Indexable Slotting Cutter |
