Product Specifications
| Manufacturer Part Number | 03308053 |
| Cutting Diameter (Decimal Inch) | 0.539" |
| Cutting Diameter (mm) | 13.70mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 0.315" |
| Contact Surface Diameter Machine Side (mm) | 8.00mm |
| Maximum Cutting Depth (Decimal Inch) | 0.071" |
| Maximum Cutting Depth (mm) | 1.80mm |
| Maximum Cutting Depth Insert (Decimal Inch) | 0.071" |
| Maximum Cutting Depth Insert (mm) | 1.80mm |
| Spot Chamfer (Decimal Inch) | 0.008" |
| Spot Chamfer (mm) | 0.20mm |
| Cutting Width (Decimal Inch) | 0.181" |
| Cutting Width (mm) | 4.60mm |
| Functional Length (Decimal Inch) | 0.181" |
| Functional Length (mm) | 4.60mm |
| Cutting Edge Count | 1 |
| Material | Carbide |
| Cutting Direction | Right Hand |
| Tool Cutting Edge Angle (Degree) | 45 Degree |
| Peripheral Effective Cutting Edge Count | 6 |
| Peripheral Edges In The Tool | 6 |
| Product Type | T-Slot Milling Tip Insert |
