Product Specifications
| Manufacturer Part Number | 03301692 |
| Body Diameter (Decimal Inch) | 1.378" |
| Body Diameter (mm) | 35.00mm |
| Minimum Connection Bore Diameter (Decimal Inch) | 0.394" |
| Minimum Connection Bore Diameter (mm) | 10.00mm |
| Maximum Connection Bore Diameter (Decimal Inch) | 0.394" |
| Maximum Connection Bore Diameter (mm) | 10.00mm |
| Body Length (Decimal Inch) | 1.535" |
| Body Length (mm) | 39.00mm |
| Functional Length Secondary (Decimal Inch) | 1.772" |
| Functional Length Secondary (mm) | 45.00mm |
| Protruding Length (Decimal Inch) | 2.559" |
| Protruding Length (mm) | 65.00mm |
| Clamping Length (Decimal Inch) | 1.417" |
| Clamping Length (mm) | 36.00mm |
| Overall Length (Decimal Inch) | 3.819" |
| Overall Length (mm) | 97.00mm |
| Data Chip Provision | 1 |
| Product Type | End Mill Holder |
