Product Specifications
| Manufacturer Part Number | 03280830 |
| Fixing Hole Diameter (Decimal Inch) | 0.110" |
| Fixing Hole Diameter (mm) | 2.80mm |
| Inscribed Circle Diameter (Decimal Inch) | 0.250" |
| Inscribed Circle Diameter (mm) | 6.35mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.421" |
| Cutting Edge Effective Length (mm) | 10.70mm |
| Theoretical Cutting Edge Length (Decimal Inch) | 0.437" |
| Theoretical Cutting Edge Length (mm) | 11.10mm |
| Corner Radius (Decimal Inch) | 0.016" |
| Corner Radius (mm) | 0.40mm |
| Insert Thickness (Decimal Inch) | 0.125" |
| Insert Thickness (mm) | 3.18mm |
| Cutting Edge Count | 2 |
| Clearance Angle Major (Degree) | 7 Degree |
| Insert Included Angle (Degree) | 35 Degree |
| Insert Hand | Neutral |
| Insert Size And Shape | VC1103 |
| Insert Shape Code | V |
| Material | Carbide |
| Product Type | Turning Insert |
