Product Specifications
| Manufacturer Part Number | 03273098 |
| Insert Length (Decimal Inch) | 0.567" |
| Insert Length (mm) | 14.40mm |
| Wiper Edge Length (Decimal Inch) | 0.028" |
| Wiper Edge Length (mm) | 0.70mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.516" |
| Cutting Edge Effective Length (mm) | 13.10mm |
| Corner Radius (Decimal Inch) | 0.122" |
| Corner Radius (mm) | 3.10mm |
| Cutting Edge Count | 4 |
| Cutting Geometry Type Technical | M11 |
| Insert Size And Shape | XNHQ1407 |
| Insert Rake Angle (Degree) | 16 Degree |
| Insert Hand | Neutral |
| Material | Carbide |
| Product Type | Disc Milling Insert |
