Product Specifications
| Manufacturer Part Number | 03062862 |
| Body Diameter (Decimal Inch) | 3.150" |
| Body Diameter (mm) | 80.00mm |
| Connection Diameter Machine Side (Decimal Inch) | 3.150" |
| Connection Diameter Machine Side (mm) | 80.00mm |
| Shank Diameter (Decimal Inch) | 3.150" |
| Shank Diameter (mm) | 80.00mm |
| Thread Diameter Size | G 3/4 |
| Body Length (Decimal Inch) | 16.575" |
| Body Length (mm) | 421.00mm |
| Functional Length (Decimal Inch) | 29.173" |
| Functional Length (mm) | 741.00mm |
| Shank Length (Decimal Inch) | 12.598" |
| Shank Length (mm) | 320.00mm |
| Overall Length (Decimal Inch) | 29.173" |
| Overall Length (mm) | 741.00mm |
| Coolant Entry Thread Size | G 3/4 |
| Product Type | Shrink-Fit Tool Holder |
