Product Specifications
| Manufacturer Part Number | 03002203 |
| Fixing Hole Diameter (mm) | 2.00mm |
| Inscribed Circle Diameter (mm) | 5.16mm |
| Insert Length (mm) | 11.73mm |
| Corner Radius (mm) | 6.00mm |
| Insert Thickness (mm) | 2.37mm |
| Cutting Edge Count | 2 |
| Clearance Angle Major (Degree) | 11 Degree |
| Insert Rake Angle (Degree) | 12 Degree |
| Insert Hand | Right Hand |
| Cutting Geometry Type | ME |
| Cutting Geometry Type Technical | ME03 |
| Pocket Seat Code of The Cutter | 218.20-060 |
| Insert Size And Shape | 218.20-060 |
| Insert Shape Code | 218.20 |
| Material | Carbide |
| Product Type | Milling Insert |
