Product Specifications
| Manufacturer Part Number | 03000052 |
| Coating | AlTiN |
| Connection Diameter Machine Side (Decimal Inch) | 0.433" |
| Shank Diameter (Decimal Inch) | 0.433" |
| Flute Helix Angle (Degree) | 48 Degree |
| Cutting Direction | Right Hand |
| Functional Length (Decimal Inch) | 3.802" |
| Usable Length (Decimal Inch) | 2.795" |
| Material | HSS-E-PM |
| Number of Flutes | 3 |
| Overall Length (Decimal Inch) | 3.937" |
| Recommended Premachined Hole Diameter (Decimal Inch) | 0.504" |
| Shank Type | Cylindrical |
| Tap Chamfer Length (Decimal Inch) | 0.135" |
| Thread Diameter (Decimal Inch) | 0.551" |
| Thread Tolerance Class | 6HX |
| Threading Chamfer Length (Decimal Inch) | 0.148" |
| Thread Form Type | MF |
| Thread Length (Decimal Inch) | 0.591" |
| Product Series | MTH |
| Product Type | Spiral Flute Tap |
