Product Specifications
| Manufacturer Part Number | 02975005 |
| Minimum Cutting Diameter Internal (Decimal Inch) | 1.575" |
| Minimum Cutting Diameter Internal (mm) | 40.00mm |
| Minimum Cutting Diameter Internal 3 (Decimal Inch) | 9.449" |
| Minimum Cutting Diameter Internal 3 (mm) | 240.00mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.260" |
| Contact Surface Diameter Machine Side (mm) | 32.00mm |
| Overall Length (Decimal Inch) | 1.221" |
| Overall Length (mm) | 31.00mm |
| Functional Length (Decimal Inch) | 0.709" |
| Functional Length (mm) | 18.00mm |
| Maximum Radial Cutting Depth (Decimal Inch) | 0.236" |
| Maximum Radial Cutting Depth (mm) | 6.00mm |
| Shank Type | GL-Connection |
| Coolant Entry Style Code | 1 |
| Coolant Pressure | Bar |
| Coolant Supply Property | 1 |
| Coolant Exit Style Code | 3 |
| Rake Radial Angle (Degree) | -5 Degree |
| Axial Rake Angle (Degree) | -0.26 Degree |
| Cutting Direction | Right Hand |
| Insert Clamping System | S |
| Tool Cutting Edge Angle (Degree) | 93 Degree |
| Tool Cutting Edge Angle Code | U |
| Product Type | Modular Cutting Head |
