Product Specifications
| Manufacturer Part Number | 02903472 |
| Wiper Edge Length (Decimal Inch) | 0.051" |
| Cutting edge count | 4 |
| Cutting Geometry Type Technical | MD08 |
| Insert size and shape | LOEX0804 |
| Insert Rake Angle (Degree) | 29.00 Degree |
| Insert Rake Angle (Degree) | 29.0 |
| Grade Type | Carbide PVD |
| Insert Hand | Right Hand |
| Cutting Edge Effective Length (Decimal Inch) | 0.327" |
| Corner Radius (Decimal Inch) | 0.016" |
| Insert Thickness (Decimal Inch) | 0.263" |
| Insert seat size code | 08 |
| Product Series | LOEX |
| Product Type | Milling Insert |
