Product Specifications
| Manufacturer Part Number | 02842080 |
| Fixing Hole Diameter (Decimal Inch) | 0.158" |
| Fixing Hole Diameter (mm) | 4.00mm |
| Inscribed Circle Diameter (Decimal Inch) | 0.440" |
| Inscribed Circle Diameter (mm) | 11.18mm |
| Curved Cutting Edge Radius (Decimal Inch) | 0.630" |
| Curved Cutting Edge Radius (mm) | 16.00mm |
| Corner Radius (Decimal Inch) | 0.047" |
| Corner Radius (mm) | 1.20mm |
| Insert Thickness (Decimal Inch) | 0.187" |
| Insert Thickness (mm) | 4.76mm |
| Cutting Edge Count | 3 |
| Clearance Angle Major (Degree) | 12 Degree |
| Insert Rake Angle (Degree) | 15 Degree |
| Insert Hand | Neutral |
| Cutting Geometry Type | M |
| Cutting Geometry Type Technical | M11 |
| Pocket Seat Code of The Cutter | 218.19-160 |
| Insert Size And Shape | 218.19-160 |
| Insert Shape Code | 218.19 |
| Material | Carbide |
| Product Type | Milling Insert |
