Product Specifications
| Manufacturer Part Number | 02815043 |
| Insert Gauge Length (Decimal Inch) | 1.144" |
| Insert Gauge Length (mm) | 29.06mm |
| Cutting Width (Decimal Inch) | 0.315" |
| Cutting Width (mm) | 8.00mm |
| Maximum Cutting Depth Insert (Decimal Inch) | 1.102" |
| Maximum Cutting Depth Insert (mm) | 28.00mm |
| Corner Radius (Decimal Inch) | 0.047" |
| Corner Radius (mm) | 1.20mm |
| Insert Thickness (Decimal Inch) | 0.219" |
| Insert Thickness (mm) | 5.57mm |
| Cutting Edge Count | 2 |
| Clearance Angle Major (Degree) | 7 Degree |
| Insert Hand | Neutral |
| Insert Size And Shape | LC3008 |
| Material | Carbide |
| Product Type | Multi-Directional Turning Insert |
