Product Specifications
| Manufacturer Part Number | 02602136 |
| Cutting Diameter (Decimal Inch) | 1.850" |
| Cutting Diameter (mm) | 46.99mm |
| Minimum Cutting Diameter Internal (Decimal Inch) | 1.842" |
| Minimum Cutting Diameter Internal (mm) | 46.79mm |
| Maximum Cutting Diameter Internal (Decimal Inch) | 2.047" |
| Connection Diameter Machine Side (Decimal Inch) | 1.500" |
| Connection Diameter Machine Side (mm) | 38.10mm |
| Flange Diameter (Decimal Inch) | 2.303" |
| Flange Diameter (mm) | 58.50mm |
| Shank Diameter (Decimal Inch) | 1.500" |
| Shank Diameter (mm) | 38.10mm |
| Shank Length (Decimal Inch) | 3.000" |
| Shank Length (mm) | 76.20mm |
| Usable Length (Decimal Inch) | 3.700" |
| Usable Length (mm) | 93.98mm |
| Overall Length (Decimal Inch) | 8.019" |
| Overall Length (mm) | 203.68mm |
| Adjustment Limit Minimum (Decimal Inch) | 0.004" |
| Adjustment Limit Minimum (mm) | 0.10mm |
| Adjustment Limit Maximum (Decimal Inch) | 0.098" |
| Adjustment Limit Maximum (mm) | 2.50mm |
| Coolant Entry Style Code | 3 |
| Coolant Supply Property | 1 |
| Coolant Exit Style Code | 4 |
| Tool Cutting Edge Angle (Degree) | 88 Degree |
| Product Type | Indexable Insert Drill |
