Product Specifications
| Manufacturer Part Number | 02590852 |
| Inscribed Circle Diameter (Decimal Inch) | 0.500" |
| Inscribed Circle Diameter (mm) | 12.70mm |
| Shank Width (Decimal Inch) | 1.677" |
| Shank Width (mm) | 42.60mm |
| Functional Width (Decimal Inch) | 1.307" |
| Functional Width (mm) | 33.20mm |
| Corner Radius (Decimal Inch) | 0.032" |
| Corner Radius (mm) | 0.80mm |
| Insert Thickness (Decimal Inch) | 0.188" |
| Insert Thickness (mm) | 4.76mm |
| Clearance Angle Major (Degree) | 7 Degree |
| Cutting Edge Count | 4 |
| Cutting Geometry Type Technical | P1 |
| Insert Included Angle (Degree) | 90 Degree |
| Material | Carbide |
| Product Type | Indexable Drill Insert |
