Product Specifications
| Manufacturer Part Number | 02510278 |
| Minimum Cutting Diameter (mm) | 6.01mm |
| Connection Diameter Machine Side (mm) | 16.00mm |
| Maximum Cutting Diameter (mm) | 8.00mm |
| Shank Diameter (mm) | 16.00mm |
| Maximum Cutting Depth (mm) | 2.80mm |
| Body Length (mm) | 25.00mm |
| Shank Length (mm) | 44.50mm |
| Tool Cutting Edge Angle (Degree) | 45 Degree |
| Product Type | Combination Chamfer & Countersink Drill |
