Product Specifications
| Manufacturer Part Number | 02468695 |
| Cutting Diameter Internal Minimum (mm) | 350.00mm |
| Cutting Direction | Right Hand |
| Functional Height (mm) | 40.00mm |
| Tool Cutting Edge Angle Code | L |
| Inclination Angle (Degree) | -6.00 Degree |
| Functional Length (mm) | 250.00mm |
| Head Length (mm) | 38.00mm |
| Shank Length (mm) | 213.00mm |
| Shank Type | Square shank |
| Insert seat size code | 1906 |
| Version (Internal/External/Both) | External |
| Functional Width (mm) | 50.00mm |
| Product Series | PCLNR |
| Product Type | Indexable Turning Toolholder |
