Product Specifications
| Manufacturer Part Number | 00064918 |
| Inscribed Circle Diameter (Decimal Inch) | 0.625" |
| Inscribed Circle Diameter (mm) | 15.88mm |
| Corner Chamfer Width (Decimal Inch) | 0.006" |
| Corner Chamfer Width (mm) | 0.16mm |
| Corner Radius (Decimal Inch) | 0.020" |
| Corner Radius (mm) | 0.51mm |
| Insert Thickness (Decimal Inch) | 0.242" |
| Insert Thickness (mm) | 6.15mm |
| Thread Form Type | API - External Threading |
| API Code | V040 |
| Cutting Edge Count | 3 |
| Insert Hand | Right Hand |
| Tooth Count | 1 |
| Profile Included Angle (Degree) | 60 Degree |
| Material | Carbide |
| Product Type | Laydown Threading Insert |
