Product Specifications
| Manufacturer Part Number | 00059861 |
| Cutting Diameter (Decimal Inch) | 6.299" |
| Cutting Diameter (mm) | 160.00mm |
| Connection Bore Diameter (Decimal Inch) | 2.000" |
| Connection Bore Diameter (mm) | 50.80mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 4.331" |
| Contact Surface Diameter Machine Side (mm) | 110.00mm |
| Maximum Cutting Diameter (Decimal Inch) | 6.390" |
| Maximum Cutting Diameter (mm) | 162.30mm |
| Functional Length (Decimal Inch) | 2.374" |
| Functional Length (mm) | 60.30mm |
| Depth of Key Way (Decimal Inch) | 0.441" |
| Depth of Key Way (mm) | 11.20mm |
| Keyway Width (Decimal Inch) | 0.756" |
| Keyway Width (mm) | 19.20mm |
| Rake Radial Angle (Degree) | -5 Degree |
| Rake Radial Angle (Degree) | -5 Degree |
| Rake Orthogonal Angle (Degree) | -6 Degree |
| Axial Rake Angle (Degree) | -7 Degree |
| Tool Cutting Edge Angle (Degree) | 75 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 75 Degree |
| Maximum Rotational Speed (rpm) | 6400 rpm |
| Shank Type | Arbor |
| Product Type | Face Mill for Square Insert |
