Product Specifications
| Manufacturer Part Number | 00054587 |
| Cutting Diameter (Decimal Inch) | 2.000" |
| Cutting Diameter (mm) | 50.80mm |
| Connection Bore Diameter (Decimal Inch) | 0.750" |
| Connection Bore Diameter (mm) | 19.05mm |
| Contact Surface Diameter Machine Side (Decimal Inch) | 1.850" |
| Contact Surface Diameter Machine Side (mm) | 47.00mm |
| Maximum Helical Interpolation Hole Diameter (Decimal Inch) | 3.921" |
| Maximum Helical Interpolation Hole Diameter (mm) | 99.60mm |
| Minimum Helical Interpolation Hole Diameter (Decimal Inch) | 3.685" |
| Minimum Helical Interpolation Hole Diameter (mm) | 93.60mm |
| Functional Length (Decimal Inch) | 2.250" |
| Functional Length (mm) | 57.15mm |
| Maximum Depth of Cut (mm) | 14.00mm |
| Maximum Depth of Cut (Decimal Inch) | 0.551" |
| Depth of Key Way (Decimal Inch) | 0.185" |
| Depth of Key Way (mm) | 4.70mm |
| Keyway Width (Decimal Inch) | 0.323" |
| Keyway Width (mm) | 8.20mm |
| Coolant Entry Style Code | 1 |
| Cutting Pitch Density | Close |
| Coolant Supply Property | 1 |
| Coolant Exit Style Code | 3 |
| Rake Radial Angle (Degree) | -3 Degree |
| Rake Radial Angle (Degree) | -3 Degree |
| Rake Orthogonal Angle (Degree) | -3 Degree |
| Axial Rake Angle (Degree) | 7 Degree |
| Tool Cutting Edge Angle (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 90 Degree |
| Maximum Ramping Angle (Degree) | 8 Degree |
| Maximum Rotational Speed (rpm) | 30000 rpm |
| Shank Type | Arbor |
| Product Type | Indexable Copy End Mill |
