Product Specifications
| Manufacturer Part Number | 00040032 |
| Cutting Diameter (Decimal Inch) | 1.000" |
| Cutting Diameter (mm) | 25.40mm |
| Connection Diameter Machine Side (Decimal Inch) | 1.250" |
| Connection Diameter Machine Side (mm) | 31.75mm |
| Shank Diameter (Decimal Inch) | 1.250" |
| Shank Diameter (mm) | 31.75mm |
| Protruding Length (Decimal Inch) | 6.215" |
| Protruding Length (mm) | 157.86mm |
| Shank Length (Decimal Inch) | 4.996" |
| Shank Length (mm) | 126.90mm |
| Overall Length (Decimal Inch) | 8.577" |
| Overall Length (mm) | 217.86mm |
| Maximum Depth of Cut (mm) | 22.00mm |
| Maximum Depth of Cut (Decimal Inch) | 0.866" |
| Coolant Entry Style Code | 1 |
| Cutting Pitch Density | Normal |
| Coolant Supply Property | 1 |
| Coolant Exit Style Code | 3 |
| Tool Cutting Edge Angle (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 90 Degree |
| Number of Flute | 2 |
| Maximum Ramping Angle (Degree) | 45 Degree |
| Maximum Rotational Speed (rpm) | 16900 rpm |
| Sphere Angle (Degree) | 180 Degree |
| Insert Shape Code | 218.20 |
| Shank Type | Cylindrical |
| Product Type | Indexable Ball Nose End Mill |
