Product Specifications
| Manufacturer Part Number | 00030469 |
| Fixing Hole Diameter (mm) | 5.80mm |
| Inscribed Circle Diameter (mm) | 15.88mm |
| Insert Length (mm) | 38.26mm |
| Corner Radius (mm) | 20.00mm |
| Insert Thickness (mm) | 8.06mm |
| Cutting Edge Count | 2 |
| Clearance Angle Major (Degree) | 15 Degree |
| Insert Rake Angle (Degree) | -2 Degree |
| Insert Hand | Right Hand |
| Cutting Geometry Type | M |
| Cutting Geometry Type Technical | M10 |
| Pocket Seat Code of The Cutter | 218.20-200 |
| Insert Size And Shape | 218.20-200 |
| Insert Shape Code | 218.20 |
| Material | Carbide |
| Product Type | Milling Insert |
