Product Specifications
| Manufacturer Part Number | 00029220 |
| Fixing Hole Diameter (Decimal Inch) | 0.102" |
| Fixing Hole Diameter (mm) | 2.60mm |
| Inscribed Circle Diameter (Decimal Inch) | 0.250" |
| Inscribed Circle Diameter (mm) | 6.35mm |
| Corner Radius (Decimal Inch) | 0.016" |
| Corner Radius (mm) | 0.40mm |
| Insert Thickness (Decimal Inch) | 0.094" |
| Insert Thickness (mm) | 2.38mm |
| Clearance Angle Major (Degree) | 11 Degree |
| Cutting Edge Count | 4 |
| Pocket Seat Code of The Cutter | SP.X0602 |
| Insert Size And Shape | SPMX0602 |
| Insert Included Angle (Degree) | 90 Degree |
| Insert Rake Angle (Degree) | 20 Degree |
| Material | Carbide |
| Product Type | Milling Insert |
