Product Specifications
| Manufacturer Part Number | 00023793 |
| Cutting Diameter (Decimal Inch) | 0.039" |
| Cutting Diameter (mm) | 1.00mm |
| Maximum Cutting Diameter (Decimal Inch) | 0.630" |
| Maximum Cutting Diameter (mm) | 16.00mm |
| Neck Diameter (Decimal Inch) | 0.453" |
| Neck Diameter (mm) | 11.50mm |
| Maximum Depth of Cut (Decimal Inch) | 0.295" |
| Maximum Depth of Cut (mm) | 7.50mm |
| Corner Chamfer Width (Decimal Inch) | 0.295" |
| Corner Chamfer Width (mm) | 7.50mm |
| Cutting Edge Effective Length (Decimal Inch) | 0.295" |
| Cutting Edge Effective Length (mm) | 7.50mm |
| Functional Length (Decimal Inch) | 0.677" |
| Functional Length (mm) | 17.20mm |
| Torque (Nm) | 16Nm |
| Cutting Edge Count | 1 |
| Material | Carbide |
| Tool Cutting Edge Angle (Degree) | 45 Degree |
| Tool Cutting Edge Angle In Feed Direction End (Degree) | 90 Degree |
| Tool Cutting Edge Angle In Feed Direction Side (Degree) | 45 Degree |
| Corner Chamfer Angle (Degree) | 45 Degree |
| Peripheral Effective Cutting Edge Count | 2 |
| Peripheral Edges In The Tool | 2 |
| Product Type | Chamfer Milling Tip Insert |
