Product Specifications
| Drill Diameter (Inch) | 5/16" |
| Drill Diameter (Decimal Inch) | 0.3125" |
| Finish/Coating | Uncoated |
| Max Bore Depth (Decimal Inch) | 1.272" |
| Flute Length (Decimal Inch) | 0.860" |
| Flute Taper Included | 18 |
| Shank Diameter (Inch) | 5/16" |
| Shank Diameter (Decimal Inch) | 0.3125" |
| Length from Holder (Decimal Inch) | 1.353" |
| Overall Length (Inch) | 2-1/2" |
| Overall Length (Decimal Inch) | 2.50" |
| Point Angle | 118 Degree |
| Web Thickness (Decimal Inch) | 0.040" |
