Product Specifications
| Drill Diameter (Inch) | 3/16" |
| Drill Diameter (Decimal Inch) | 0.1875" |
| Finish/Coating | Uncoated |
| Max Bore Depth (Decimal Inch) | 1.035" |
| Flute Length (Decimal Inch) | 0.567" |
| Flute Taper Included | 16 |
| Shank Diameter (Inch) | 3/16" |
| Shank Diameter (Decimal Inch) | 0.1875" |
| Length from Holder (Decimal Inch) | 1.090" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.00" |
| Point Angle | 118 Degree |
| Web Thickness (Decimal Inch) | 0.028" |
