Product Specifications
| Manufacturer Part Number | IT-3602000X |
| Minimum Bore Diameter (Decimal Inch) | 0.3820" |
| Maximum Bore Diameter (Decimal Inch) | 2.000" |
| Maximum Bore Diameter (Inch) | 2" |
| Projection (Decimal Inch) | 0.0850" |
| Shank Diameter (Decimal Inch) | 0.3750" |
| Shank Diameter (Inch) | 3/8" |
| Shank Diameter(mm) | 0.1725" |
| Offset (Decimal Inch) | 0.049" |
| Radius (Decimal Inch) | 0.0020" |
| Angle per Side (Degree) | 30 Degree |
| Included Angle (Degree) | 60 Degree |
| Hand Direction | Right Hand |
| Neck Diameter (Decimal Inch) | 0.2700" |
| Overall Length (Decimal Inch) | 4.00" |
| Overall Length (Inch) | 4" |
| Thread Size | 7-32" |
| TPI | 7-32 TPI |
| Coating | AlTiN |
| Product Type | Single Point Threading Tool |
