Features:
- Triple margin design improves hole stability and size control while providing superior finish, roundness and cylindricity
- Self-stabilizing pyramid point design stabilizes the drill on contact with the workpiece
- Open flute structure efficiently transports chips while maintaining strength at high feed rates
- Sculpted gash allows chips to easily flow away from the drill center
Product Specifications
| Cutting Diameter (mm) | 7.5mm |
| Shank Diameter (mm) | 8.0mm |
| Length of Cut (mm) | 41.0mm |
| Overall Length (mm) | 79.0mm |
| Shank Length (mm) | 36.0mm |
| Cut of Direction | RHC |
| Flute Type | Spiral |
| Cleared Length (mm) | 29 mm |
| Helix Angle | 30 Degree |
| Point Angle | 124 Degree |
| Coating | TiB2 |
| Number of Flutes | 3 |
