Features:
- 3-margin design improves hole stability and size control while providing superior finish, roundness and cylindricity
- Self-stabilizing pyramid point design stabilizes the drill on contact with the workpiece
- Open flute structure efficiently transports chips while maintaining strength at high feed rates
- Sculpted gash allows chips to easily flow away from the drill center
- Recommended for materials ≤ 43 HRC (≤ 400 BHN)
Product Specifications
| Cutting Diameter (Inch) | 14 mm |
| Shank Diameter (Inch) | 14.1 mm |
| Length of Cut (Inch) | 77.1 mm |
| Overall Length (Inch) | 124.1 mm |
| Shank Length (Inch) | 45.1 mm |
| Cut of Direction | RHC |
| Flute Type | Spiral |
| Cleared Length (Inch) | 60 mm |
| Helix Angle | 30 Degree |
| Point Angle | 124 Degree |
| Coating | TM |
| Number of Flutes | 3 |
