Helical Solutions

Helical Solutions 86345 | HMAF-FE-4 0.5000" Diameter x 0.5000" Shank x 3.0000" OAL x 0.0313" Radius 4 Flute Tplus Coated Barrel Cutter End Mill

Helical Solutions 86345 | HMAF-FE-4 0.5000" Diameter x 0.5000" Shank x 3.0000" OAL x 0.0313" Radius 4 Flute Tplus Coated Barrel Cutter End Mill

SKU: 25280743

Precio habitual $266.40 USD
Precio habitual $266.40 USD Precio de oferta $266.40 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

UPC:

Weight: 104 Grams

Ver todos los detalles

Product Specifications
# Manufacturer Number 86345
Cutter Diameter (Inch) 1/2"
Cutter Diameter (Decimal Inch) 0.5000"
Shank Diameter (Inch) 1/2"
Shank Diameter (Decimal Inch) 0.5000"
Overall Length (Inch) 3"
Overall Length (Decimal Inch) 3.0000"
Length of Cut (Inch) 3/32"
Length of Cut (Decimal Inch) 0.0866"
Corner Radius (Decimal Inch) 0.0313"
Radius (Decimal Inch) 16.0000"
Tip Radius (Inch) 1/8"
Tip Radius (Decimal Inch) 0.1250"
Included Angle 150 Degree
Number of Flutes 4
LOC Multiple (0.1x)
Benefit Multiple 8x
Center Cutting (Yes/No) Yes
Coating Tplus
