Product Specifications
Milling Diameter (Inch) | 3/16" |
Milling Diameter (Decimal Inch) | 0.1875" |
Number of Flutes | 2 |
Length Of Cut (Decimal Inch) | 0.1500" |
Overall Reach (Inch) | 1-11/32" |
Overall Reach (Decimal Inch) | 1.3430" |
Finish/Coating | TiB2 |
Shank Diameter (Inch) | 1/4" |
Shank Diameter (Decimal Inch) | 0.2500" |
Single or Double End | Single |
Overall Length (Inch) | 2-1/2" |
Overall Length (Decimal Inch) | 2.5000" |
Center Cutting (Yes/No) | Yes |
Tapered Reach (Decimal Inch) | 1.3430" |
Tapered Reach (Inch) | 1-11/32" |
Neck Angle | 1.5 Degrees |
LOC Multiple | 0.8x |
Type | II |
Metric (Yes/No) | No |
