Features
- 300 Degree spherical ball
- Designed for undercutting, deburring and multi-axis machining
- Center cutting
- Solid carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | 984040-C3 |
| Cutter Diameter (Inch) | 0.6250" (5/8) |
| Neck Diameter (Inch) | 0.2920" |
| Length of Cut (Inch) | 0.5830" |
| Overall Reach (Inch) | 1.5830" |
| Overall Length (Inch) | 3.5000" (3-1/2) |
| Neck Length (Inch) | 1.0000" (1) |
| Radius (Inch) | 0.3125" (5/16) |
| Shank Diameter (Inch) | 0.6250" (5/8) |
| Wrap Angle | 300 Degree |
| Number of Flutes | 4 |
| Coating | C3 |
| Profile | Spherical |
