Product Specifications
| Minor Diameter (Decimal Inch) | 0.0910" |
| Overall Length (Decimal Inch) | 1.5000" |
| Overall Length (Inch) | 1-1/2" |
| End To Center (Decimal Inch) | 0.1080" |
| Min Opening Width (Decimal Inch) | 0.1010" |
| End Length (Decimal Inch) | 0.0400" |
| Chamfer Length (Decimal Inch) | 0.0220" |
| Radius (Decimal Inch) | 0.0060" |
| Angle Per Side | 45 Degree |
| Included Angle | 90 Degree |
| Number of Flutes | 4 |
| Max Opening Width (Decimal Inch) | 0.1350" |
| Shank Diameter (Decimal Inch) | 0.1250" |
| Shank Diameter (Inch) | 1/8" |
| Metric | No |
| Coating | Uncoated |
