Harvey Tool

Harvey Tool 826331 | 0.0310" (1/32) Diameter x 0.1250" (1/8) Shank x 0.1560" (5/32) LOC x 1.5000" (1-1/2) OAL 2 Flute Uncoated Carbide Plastics 2 Flute Square End Mill

Harvey Tool 826331 | 0.0310" (1/32) Diameter x 0.1250" (1/8) Shank x 0.1560" (5/32) LOC x 1.5000" (1-1/2) OAL 2 Flute Uncoated Carbide Plastics 2 Flute Square End Mill

SKU: 25211499

$48.50 USD
$48.50 USD $48.50 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

UPC:

Weight: 9 Grams

17 en existencias

Free Shipping on Orders Over $75

Ver todos los detalles

These unique tools, Harvey Tool's End Mills for Plastics - Square Downcut - 2 Flute, prevent fraying and chip-out on the top of the workpiece, resist lifting on vacuum tables, and are designed with large flute valleys to maximize chip removal and performance.

  • High rake, high relief design with large flute valley maximizes chip removal and performance
  • Prevents fraying and chip-out on the top of the workpiece
  • Prevents lifing on vacuum tables
  • CNC ground in the USA
  • Solid carbide

Product Specifications
Tool Number 826331
Cutter Diameter (Inch) 0.0310" (1/32)
Length of Cut (Inch) 0.1560" (5/32)
Overall Length (Inch) 1.5000" (1-1/2)
Flutes 2
LOC Multiple 5x
Shank Diameter (Inch) 0.1250" (1/8)
Coating Uncoated
