Product Specifications
| Manufacturer Part Number | 820250-C3 |
| Length of Cut (Decimal Inch) | 0.176" |
| Overall Length (Decimal Inch) | 3.000" |
| Overall Length (Inch) | 3" |
| Tip Diameter (Decimal Inch) | 0.080" |
| Angle per Side (Degree) | 50 Degree |
| Included Angle (Degree) | 10 Degree |
| Number of Flute | 4 |
| Type | III |
| Shank Diameter (Decimal Inch) | 0.500" |
| Shank Diameter (Inch) | 1/2" |
| Metric | No |
| Coating | C3 |
| Center Cutting | Yes |
| Product Type | Chamfer Cutter |
