Harvey Tool

Harvey Tool 76208 | 0.0080" (0.2 mm) Diameter x 0.1250" (1/8) Shank x 0.0240" LOC x 1.5000" (1-1/2) OAL x 2 Flutes Uncoated Carbide Square End Mill

Harvey Tool 76208 | 0.0080" (0.2 mm) Diameter x 0.1250" (1/8) Shank x 0.0240" LOC x 1.5000" (1-1/2) OAL x 2 Flutes Uncoated Carbide Square End Mill

SKU: 25211411

$54.90 USD
$54.90 USD $54.90 USD
Oferta Agotado
Los gastos de envío se calculan en la pantalla de pago.

UPC:

Weight: 9 Grams

15 en existencias

Free Shipping on Orders Over $75

Ver todos los detalles

Miniature End Mills - Square - Long Reach, Standard Flute feature a reduced neck diameter to avoid heeling.

  • CNC ground in the USA
  • Center Cutting
  • Solid Carbide

Product Specifications
Tool Number 76208
Cutter Diameter (Inch) 0.0080" (.2 mm)
Neck Diameter (Inch) 0.0075"
Length of Cut (Inch) 0.0240"
Neck Length (Inch) 0.0410"
Overall Reach (Inch) 0.0650"
Overall Length (Inch) 1.5000" (1-1/2)
Flutes 2
LOC Multiple 3x
Reach Multiple 8x
Shank Diameter (Inch) 0.1250" (1/8)
Coating Uncoated
