Features
- Designed for deep cavity profiling
- 2 Degree tapered neck design minimizes deflection and maximizes wall clearance
- Length of cut = 1½ x diameter
- Neck behind length of cut is reduced for 1x diameter
- h6 shank tolerance for high precision tool holders
- Center cutting
- Solid carbide
- CNC ground in the USA
Product Specifications
| Manufacturer Part Number | 734408-C6 |
| Cutter Diameter (Inch) | 0.1250" (1/8) |
| Neck Diameter (Inch) | 0.2500" (1/4) |
| Minor Diameter (Inch) | 0.1150" |
| Length of Cut (Inch) | 0.1880" |
| Tapered Reach (Inch) | 2.2500" (2-1/4) |
| Overall Reach (Inch) | 2.5000" (2-1/2) |
| Overall Length (Inch) | 4.0000" (4) |
| Neck Length (Inch) | 0.3130" |
| Shank Diameter (Inch) | 0.3125" (5/16) |
| Neck Angle | 4 Degree |
| Number of Flutes | 4 |
| LOC Multiple | (1.5x) |
| Coating | C6 |
| Profile | Ball |
