Product Specifications
| Manufacturer Part Number | 700100-C3 |
| Cutter Diameter (Decimal Inch) | 0.124" |
| Drill Diameter(Decimal Inch) | 0.067" |
| Drill Diameter (mm) | 1.70mm |
| Flute Length (Decimal Inch) | 0.168" |
| Overall Length (Inch) | 2" |
| Overall Length (Decimal Inch) | 2.000" |
| Point Angle (Degree) | 130 Degree |
| Number of Flute | 2 |
| Shank Diameter (Inch) | 1/8" |
| Shank Diameter (Decimal Inch) | 0.125" |
| Coating | C3 |
| Drill Length (Decimal Inch) | 0.101" |
| Product Type | Combined Drill Counterbore |
