Features:
- Combination countersink & thread mill
- Axial coolant fed channel for enhanced chip removal rates
- This tool is for a specific pitch with corrected thread profile
- Pre-drilled hole is required
Product Specifications
| Manufacturer Part Number | GF332106.0277 |
| Thread Size | M 10x1.25 |
| Thread Diameter Size | M 10 |
| Thread Standard | MF |
| Thread Pitch (mm) | 1.25mm |
| Overall Length (mm) | 80.00mm |
| Flute Length (mm) | 20.70mm |
| Shank Tolerance | h6 |
| Tool Cylindrical - Shank Style | Weldon Flat - HB |
| Shank Standard | DIN 6535 |
| Flute Direction | Right Hand |
| Group Length | 2xD |
| Coolant Supply Property | Internal |
| Coolant Fed | Axial |
| Number of Flute | 3 |
| Flute Helix Angle (Degree) | 30 Degree |
| Cutting Edge Material | Carbide |
| Coating | TiCN |
| Tool Type | SHUR-THREAD |
| Application | Thread Milling |
| Product Type | Thread Mill |
