Features:
- High performance design for universal applications including mold & die milling
- Multi-functional tool Wear resistant sub-micro grain carbide
Product Specifications
| Manufacturer Part Number | 3835A.002002 |
| Cutting Diameter (Decimal Inch) | 0.079" |
| Cutting Diameter (mm) | 2.00mm |
| Corner Radius (mm) | 0.20mm |
| Overall Length (mm) | 57.00mm |
| Flute Length (mm) | 3.00mm |
| Shank Tolerance | h5 |
| Tool Cylindrical - Shank Style | Cylindrical - HA |
| Shank Standard | DIN 6535 |
| Flute Direction | Right Hand |
| Group Length | Stub Length |
| Coolant Supply Property | External |
| Coolant Fed | No |
| Number of Flute | 4 |
| Flute Helix Angle (Degree) | 30 Degree |
| Cutting Edge Material | Carbide |
| Coating | TIALN |
| Tool Type | Torus |
| End Mill - End Style | Square & Corner Radius End Mills |
| End Shape | TORUS |
| Application | Finishing |
| Product Type | Torus End Mill |
