Features:
- Solid carbide one flute design for etching metal parts
- Multi-functional tool design with one flute
- Bright, uncoated surface finish
Product Specifications
| Manufacturer Part Number | 1710.09008 |
| Cutting Diameter (Decimal Inch) | 0.315" |
| Cutting Diameter (mm) | 8.00mm |
| Overall Length (mm) | 79.00mm |
| Flute Length (mm) | 9.00mm |
| Shank Tolerance | h6 |
| Tool Cylindrical - Shank Style | Cylindrical - HA |
| Shank Standard | DIN 6535 |
| Connection Diameter Machine Side | BT40 |
| Flute Direction | Right Hand |
| Group Length | Standard Length |
| Coolant Supply Property | External |
| Coolant Fed | No |
| Number of Flute | 1 |
| Point Angle (Degree) | 90 Degree |
| Cutting Edge Material | Carbide |
| Coating | Bright |
| Tool Type | Engraving tool |
| End Mill - End Style | Engraving & Chamfer Tools |
| End Shape | Chamfer |
| Application | Marking & stenciling |
| Product Type | Engraving Cutter |
