Features:
- H5 bore tolerance for improved concentricity and tool life
- Taper ground to AT3 specification for maximum spindle contact
- Balanced to 15,000 RPM at G6.3
Product Specifications
| Taper | SBT40 |
| Body Diameter (mm) | 44.45mm |
| Body Width (Inch) | 1.75" |
| Overall Diameter (Inch) | 2.48" |
| Bore Size (Inch) | 0.75" |
| Projection (Inch) | 4" |
| Nose Diameter (Inch) | 1.75" |
| Overall Length (Inch) | 6.575" |
